Smart Flip Badge Logo Car Rear View Reversing Camera For VW Golf 5 6 7 MK6 MK7 Passat cc B6 B7 B8 POLO Magotan Beetle CAM

Golf 7/GTI/R/GTE/R-Line
(Golf7/7.5 All series)
Golf7.5/GTI/R/GTE/R-Line
Golf Mk7/7.5/GTI/R

CVBS list:

1. Drain Pipe:connect flip camera white outfall and trunk drain hole.Big head towards trunk.

2. MIB conversion cable: used to transfer the original vehicle MIB screen video transmission, the yellow RCA interface is connected to the No.4 line, and the blue interface is inserted into the MIB socket of the DVD. Tip: AHD camera only support AHD monitor!

3. Blue line:signal line,connect driving light positive or connect filter“driving rear-view electric” line.

4. Red line:power cord is positive which must connect DVD usual power 12V, connect ACC will leading trunk don’t open.

5. Black line:power cord is negative which connect DVD negative. 6. Trunk switch plug:butt car trunk locking connector.

7. Video output: connect DVD rear panel “driving rear-view input” plug. 8. Driving test control line:connect with driving test line of DVD line.
